| Mass | Approx. 3.8 kg (body only without lens, VF, Mic) |
| Dimensions (W x H x D) | 150 x 269 x 332 mm (excluding protrusions, body only) |
| Power Requirements | DC 12 V (11 V~17.0 V) |
| Power Consumption | Approx. 35W (while XAVC recording, color LCD on) |
| MPEG4 SStP (SR-Lite 4:2:2) | 1920x1080/59.94i,50i,29.97P,23.98P,25P |
| XAVC Intra | 1920x1080/59.94i, 50i, 29.97P, 25P, 23.98P
1280x720/59.94P, 50P |
| XAVC Long 50/35/25Mbps | 1920x1080/59.94i, 50i, 59.94P, 50P, 29.97P, 25P, 23.98P
1280x720/59.94P, 50P |
| MPEG HD422 | 1920x1080/59.94i, 50i, 29.97P, 25P, 23.98P
1280x720/59.94P, 50P, 29.97P, 25P, 23.98P |
| MPEG HD420 | 1920x1080/59.94i, 50i, 29.97P, 25P, 23.98P
1440x1080/59.94i, 50i
1280x720/59.94P, 50P |
| MPEG IMX | 720x480/59.94i(50M)
720x576/50i(50M) |
| DVCAM | 720x480/59.94i(25M)
720x576/50i(25M) |
| HD Codecs (Audio) | LPCM 24 bits, 48 kHz, 4 channels |
| MPEG IMX (Audio) | LPCM 16/24 bits, 48 kHz, 4 channels |
| DVCAM (Audio) | LPCM 16 bits, 48 kHz, 4 channels |
| XAVC Proxy 9/3/1/0.5Mbps | AVC/H.264 Main Profile 4:2:0 Long GOP, VBR, 9/3/1/0.5Mbps |
| XAVC Proxy (Audio) | AAC-LC, 128kbps, 2 channels |
| Lens Mount | Sony 2/3-inch type bayonet mount |
| Imaging Device (Type) | 3-chip 2/3-type Full HD CCD, PowerHAD FX |
| Effective Picture Elements | 1920 (H) x 1080 (V) |
| Optical System | F1.4 prism system |
| Built-in Filters | ND Filter (Optical filter) 1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND
CC Filter (Electrical filter) A: 3200K, B: 4300K, C: 5600K, D: 6300K |
| Sensitivity (2000 lx, 89.9% reflectance) | F12 (typical) (1920 x 1080/50i mode) |
| Minimum Illumination | 0.016 lx (typical) (1920 x 1080/59.94i mode, F1.4, +42 dB gain, with 16-frame accumulation) |
| S/N Ratio | 60 dB(NS:ON) |
| Horizontal Resolution | 1,000 TV lines or more (1920 x 1080i mode) |
| Audio Input | XLR-type 3-pin (female) (x2), Line/Mic/Mic +48 V selectable |
| Video Output | BNC (x1) HD-Y or Analog composite |
| Audio Output | XLR-type 5-pin |
| SDI Output | BNC (x2), HD-SDI/SD-SDI selectable |
| i.LINK | No |
| Timecode Input | BNC (x1) |
| Timecode Output | BNC (x1) |
| Genlock Input | BNC (x1) |
| USB (Type-A: Host 3.0/2.0) | for Dubbing to HDD/SSD |
| USB (Type-A: Host 2.0) | for Wi-Fi module (IFU-WML3), and LTE Dongle |
| USB (Type-B: Device 2.0) | for PC connection as mass storage mode |
| Headphone Output | Stereo mini jack (x1) |
| DC Input | XLR-type 4-pin |
| Remote | 8-pin |
| HDMI Output | HDMI connector (Type A) |
| Viewfinder | Option HDVF-20A, HDVF-200, CBK-VF02 |
| Built-in LCD Monitor | 3.5 type Approx. 1.56M dots, 16:9 |
| Type | SxS Card slot (x2)
XQD Card and SDHC Card can be used with an adaptor |
| Wi-Fi | Yes |
| NFC | No |
| GPS | Yes |
| MI Shoe | No |
| Note | * Please note that these Specifications are subject to change |
