| Mass | Approx. 2.4 kg (5 lb 4.7 oz) (body) |
| Approx. 2.8 kg (6 lb 2.8 oz) (with lens hood, eyecup, BP-U30 battery, a SxS memory card) |
| Dimensions (W x H x D) | 168×161×331 mm (6 5/8 x 6 3/8 x 13 1/8 inches) (without protrusions) |
| Power Requirements | DC 12V |
| Power Consumption | Approx. 18 W (while recording with LCD Off, EVF On, I/O Select Off and Wireless function Off) |
| Approx. 23 W (while recording with LCD On, EVF Off, HD-SDI output and Wireless function On) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to +60°C (-4°F to +140°F) |
| Battery Operating Time | With battery pack BP-U90 approx. 4.5 hours (while recording with LCD Off, EVF On, I/O Select Off and |
| Wireless function Off) |
| With battery pack BP-U60: approx. 3 hours (while recording with LCD Off, EVF On, I/O Select Off and Wireless function Off) |
| With battery pack BP-U30: approx. 1.5 hours (while recording with LCD Off, EVF On, I/O Select Off and Wireless function off) |
|
| RECORDING FORMAT (VIDEO) |
| exFAT | XAVC-I mode: CBG, max. 112Mbps, MPEG-4 H.264/AVC |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P, 50P |
| XAVC-L 50 mode: VBR, max. 50Mbps, MPEG-4 H.264/AVC |
| – 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P, 50P |
| XAVC-L 35 mode: VBR, max. 35Mbps, MPEG-4 H.264/AVC |
| – 1920×1080/59.94P, 50P, 59.94i, 50i, 29.97P, 23.98P, 25P |
| XAVC-L 25 mode: VBR, max. 35Mbps, MPEG-4 H.264/AVC |
| – 1920×1080/59.94i, 50i |
| MPEG HD422 mode: CBR, 50Mbps, MPEG-2 422P@HL |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P, 50P, 29.97P, 23.98P, 25P |
| MPEG HD420 HQ mode: VBR, max. 35Mbps, MPEG-2 MP@HL |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1440×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P,50P,23.98P(2-3 Pull Down) |
| DVCAM mode: CBR, 25Mbps, DVCAM |
| – 720×480/59.94i, 29.97PsF |
| – 720×576/50i, 25PsF |
| UDF | MPEG HD422 mode: CBR, 50Mbps, MPEG-2 422P@HL |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P, 50P, 29.97P, 23.98P, 25P |
| MPEG HD420 HQ mode: VBR, max. 35Mbps, MPEG-2 MP@HL |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1440×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P,50P,23.98P(2-3 Pull Down) |
| MPEG IMX50 mode: CBR, 50Mbps, MPEG-2 422P@ML Intra |
| – 720×486/59.94i, 29.97PsF |
| – 720×576/50i, 25PsF |
| DVCAM mode: CBR, 25Mbps, DVCAM |
| – 720×480/59.94i, 29.97PsF |
| – 720×576/50i, 25PsF |
| FAT | MPEG HD420 HQ mode: VBR, max. 35Mbps, MPEG-2 MP@HL |
| – 1920×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1440×1080/59.94i, 50i, 29.97P, 23.98P, 25P |
| – 1280×720/59.94P,50P, 29.97P, 25P, 23.98P |
| MPEG HD420 SP mode: CBR, 25Mbps, MPEG-2 MP@H-14 |
| – 1440×1080/59.94i, 50i, 23.98P(2-3 Pull Down) |
| DVCAM mode: CBR, 25Mbps, DVCAM |
| – 720×480/59.94i, 29.97PsF |
| – 720×576/50i,25PsF |
| Proxy: H.264 |
| – 1280×720: 9Mbps |
| – 640×360: 3Mbps |
| – 480×270: 1Mbps |
| – 480×270: 500Kbps |
|
| RECORDING FORMAT (AUDIO) |
| exFAT | XAVC-I mode: LPCM 24-bit, 48kHz, 4ch |
| XAVC-L mode: LPCM 24-bit, 48kHz, 4ch |
| MPEG HD422 mode: LPCM 24-bit, 48kHz, 4ch |
| MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch |
| DVCAM mode: LPCM 16-bit, 48kHz, 4ch |
| UDF | MPEG HD422 mode: LPCM 24-bit, 48kHz, 4ch |
| MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch |
| IMX50 mode: LPCM 24/16-bit, 48kHz, 4ch |
| DVCAM mode: LPCM 16-bit, 48kHz, 4ch |
| FAT | MPEG HD420 HQ mode: LPCM 16-bit, 48kHz, 4ch |
| MPEG HD420 SP mode: LPCM 16-bit, 48kHz, 4ch |
| DVCAM mode: LPCM 16-bit, 48kHz, 2ch |
| Proxy: AAC-LC, 48kHz, 128kbps, 2ch |
|
| LENS |
| Lens Mount | Fixed |
| Zoom Ratio | 17x (optical), servo/manual |
| Focal Length | f = 5.6-95.2 mm |
| (35 mm equivalent: 29.3-499 mm) |
| Iris | F1.9-F16 and close, auto/manual selectable |
| Focus | 800 mm to ∞ (Macro Off), |
| 50 mm to ∞ (Macro On, Wide), |
| 800 mm to ∞ (Macro On, Tele), |
| AF/MF/Full MF selectable |
| Image Stabilizer | On/Off selectable, shift lens |
| Filter Diameter | M77 mm, pitch 0.75mm |
|
| CAMERA SECTION |
| Imaging Device (Type) | 3-chip 1/2-inch type “Exmor” Full HD CMOS |
| Effective Picture Elements | 1920 (H) x 1080 (V) |
| Built-in Optical Filters | Clear, 1: 1/8ND, 2: 1/64ND |
| Sensitivity | F12 (typical, 1920 x 1080/59.94i mode) |
| F13 (typical, 1920 x 1080/50i mode) |
| S/N Ratio | 58dB (Y) (typical) |
| Shutter Speed | 1/32 sec to 1/2,000 sec |
| Slow & Quick Motion Function | XAVC Intra/Long mode: |
| – 1080P: 1-30 and 60 fps in NTSC setting, 1-25 and 50 fps in PAL setting |
| – 720P: 1-60 fps in NTSC setting, 1-50 fps in PAL setting |
| MPEG HD422 mode: |
| – 1080P: 1-30 fps in NTSC setting, 1-25 fps in PAL setting |
| – 720P: 1-60 fps in NTSC setting, 1-50 fps in PAL setting |
| MPEG HD420 HQ mode: |
| – 1080P: 1-30 fps |
| – 720P: 1-60 fps |
| White Balance | Preset (3200K), Memory A, Memory B/ATW |
| GPS | Yes (using firmware upgrade available early 2015) |
| Wireless functions | Yes |
| NFC | Yes |
|
| INPUT / OUTPUT |
| Audio Input | XLR-type 3-pin (female) (x2) |
| HDMI Output | Type A (x1) |
| SDI Output | BNC (x1), 3G/HD/SD selectable |
| Composite Output/ GENLOCK-IN | BNC (x1) |
| Audio Output | A/V multi connector (x1) |
| USB | USB device, mini-B (x1) |
| TC in/out | BNC (x1) |
| Lens Remote | 8-pin, round (x1) |
| DC Input | DC jack (x1) |
| Shoe | Multi Interface Shoe (x1) |
| Headphone Output | Stereo mini jack 3.5mm |
| Option | 4-pin Type A (x1) |
|
| MONITORING |
| Viewfinder | 0.45-inch type color LCD: 852 (H) x 480 (V), 16:9 |
| LCD | 3.5-inch type color LCD monitor: 960 (H) x 3 (RGB) x 540 (V), 16:9 |
|
| BUILT-IN MICROPHONE |
| Omni-directional stereo electret condenser microphone |
|
| MEDIA |
| Type | ExpressCard/34 slot (2) (for XAVC/MPEG/IMX/DV) |
| SD/SDHC (1) (for Proxy) |
