General

Mass	Approx 2.80kｇ (body) Approx. 6lb 2.8oz (body) Approx. 3.10kg (with lens hood,Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery) Approx. 6lb 13.3oz (with lens hood, Lens Cap, Microphone, Eyecup, Shoe Cap, NP-F570 battery)
Dimensions (W x H x D)	265.0 ｘ 235.0 ｘ 455.0 mm (body) 10 1/2 x 9 3/8 x 18 inches (body) 265.0 ｘ 240.0 ｘ 460.0 mm (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts) 10 1/2 x 9 1/2 x 18 1/8 inches (With the accessories (lens hood, Lens Cap, Microphone, Eyecup), excluding the grip belt and including the projecting parts)
Power Requirements	7.2V (battery pack); 8.4V (AC Adaptor)
Power Consumption	Approx. 3.3 W (with EVF On, Video light Off) Approx. 3.3 W (with LCD monitor On, Video light Off)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Battery Operating Time (Continuous Recording Time)"	Approx. 285 min with NP-F570 battery (video light Off) Approx. 135 min with NP-F570 battery (video light On)
Recording Format (Video) - HD	MPEG-4 AVC/H.264 AVCHD 2.0 format compatible
Recording Format (Video) - SD	DV(AVI)
Recording Format (Audio) - HD	Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz
Recording Format (Audio) - SD	Linear PCM 2ch, 16bit, 48kHz
Recording Frame Rate (PAL) - HD	PS(28Mbps) 1920 x 1080/50P, 16:9 FX(24Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9 FH(17Mbps) 1920 x 1080/50i, 25p, 16:9, 1280 x 720/50p, 16:9 HQ(9Mbps) 1280 x 720/50p, 16:9
Recording Frame Rate (PAL) - SD	DV(25Mbps) 720 x 576/50i, 16:9, 4:3
Recording/Playback Time	Approx.145min(Internal Media, PS, LPCM) Approx.170min(Internal Media, FX, LPCM) Approx.225min(Internal Media, FH, LPCM) Approx.380min(Internal Media, HQ, LPCM) Approx.140min(Internal Media, DV, LPCM)

Lens

Lens Mount	Fixed
Zoom Ratio	12x (optical), servo/manual
Focal Length	f = 2.9-34.8mm equivalent to f=26.8-321.6mm on 35 mm lens(16:9) equivalent to f=32.8-393.6mm on 35 mm lens(4:3)
Iris	F1.8 - F3.4 auto/manual selectable
Focus	AF/MF selectable, 10 mm to ∞ (Wide), 800 mm to ∞ (Tele)
Image Stabilizer	ON(Standard/ACTIVE)/OFF selectable, shift lens
Filter Diameter	M37 mm

Camera Section

Imaging Device (Type)	1/3.95 type(4.6mm) back-illuminated Exmor R CMOS Sensor
Imaging Device (Pixel Count)	Approx.6590K pixels
Effective Picture Elements	Approx.6140K pixels(16:9)/Approx.4600K pixels(4:3)
Minimum Illumination	1.4lux(MAN setting : SS 1/25sec , Iris F1.8 , Gain 33dB) 0.7lux(MAN setting : SS 1/12sec , Iris F1.8 , Gain 33dB)
Shutter Speed	1/6 - 1/10,000
White Balance	Preset（Indoor, Outdoor, Color temperature set range:2300-15000K) Onepush A, B, Auto selectable
Gain	0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33 dB, Auto Selectable

Input/Output

Composite Output	BNC (x1), PAL
Audio Output	RCA pin
USB	mini-AB USB2.0 Hi-speed/mass-storage/Host
Headphone Output	Stereo mini jack φ3.5mm (x1)
Speaker Output	Monaural
DC Input	DC jack
Remote	Stereo mini mini jack φ2.5mm (x1)
HDMI Output	Type A (x1)
Accessory Shoe	Multi Interface Shoe (x1), Cold Shoe (x2)

Monitoring

Viewfinder	1.0cm (0.39 type) OLED Approx. 1.44M dots
Built-in LCD Monitor	7.5cm (3.0 type) Approx. 921K dots.

Built-in Microphone

Omni-directional stereo electret condenser microphone.

Media

Internal Memory	Flash Memory 32GB
Type	Memory Stick Pro Duo™ and SD/SDHC/SDXC compatible

Built-in LED Light

Luminous intensity	1.0m / Approx.200 lx, 0.5m / Approx.800lx
Lighting angle	Approx. 30°
Color temperature	Approx. 5,500K

WiFi

Supported format	IEEE 802.11 b/g/n
Frequency band	2.4 GHz bandwidth
Security	WEP/WPA-PSK/WPA2-PSK
NFC	NFC Forum Type 3 Tag compliant

Supplied Accessories

Lens hood (1)
Lens cap (1)
Shoe Cap (1)
EVF eyecup (1)
Microphone (1)
Wind screen (1)
Video Light Diffuser (1)
USB adaptor cable (1)
Rechargeable battery pack (NP-F570) (1)
CD-ROM　Operating instructions in PDF (1)
Operating instructions (1)
AC-L100C AC adaptor (1)
AC Cable (1)
Warranty (1)
