Design

• Stand Type

  Foot Stand (Optional)

Power

• Power Supply

  AC 100 - 240 V ~ (+ / - 10%), 50 / 60 Hz

• Power Consumption (Off Mode)

  Less than 0.5 W

• Power Consumption (On Mode)

  Max: 121 / Typical: 86 / BTU (Max): 412.61

• Power Consumption (Sleep Mode)

  Less than 0.5 W

• Power Consumption (IEC 62087 Edition 2)

  85.0W

• Power Consumption (Stand-by)

  0.50 W

• Yearly Power Consumption (EU standard,kWh)

  124

Dimension

• Set Dimension (WxHxD)

  906.6 x 524.7 x 49.9 mm

• Package Dimension (WxHxD)

  1000 x 585 x 126 mm

Weight

• Set Weight with Stand

  7.52 kg

• Package Weight

  9.1 kg

Mechanical Specification

• VESA Mount

  200 x 200 mm

• Bezel Width

  9.5 (Top / Side), 15 (Bottom) mm

• Media Player Option Type

  Embbeded, SBB-C (Attachable)

Operation Conditions

• Temperature

  0 ~ 40 °C

• Humidity

  10 ~ 80%

General Feature

• Special

  Super Clear Coating, Temperature Sensor, Video Wall (15 x 15), Pivot Display, Clock Battery (80 hrs Clock Keeping), Built in Speaker (10 W x 2), Wi-Fi Module Embedded, SD Card Slot

Optional Feature

• Mount

  WMN4070SD, WMN250MD

• Specialty

  CML400D (Ceiling Mount)

• Stand

  STN-L3240E

Internal Player (MagicInfo)

• Special

  Magic Clone (to USB), Auto Source Switching & Recovery, RS232C / RJ45 MDC, Plug and Play, PIP / PBP, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain (HDCP Support), Built In MagicInfo Player S2, Firmware Update by Network, LFD New Home Screen, PC-less VideoWall, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player, PC-less Touch, MagicPresenter

• MagicInfo Support

  Yes

Eco

• Energy Efficiency Class

  B

• Lead Presence

  Presence

• Mercury Content

  0.0mg

Certification and Compliance

• EMC

  FCC (USA) Part 15, Subpart B Class A, KCC / EK (Korea): Tuner: KN13 / KN20, Tunerless: KN22 / KN24, CE (Europe): EN55022: 2006 + A1: 2007, EN55024: 1998 + A1: 2001 + A2: 2003, VCCI (Japan): VCCI V-3 / 2010.04 Class A, CCC (China): GB9254-2008, GB17625.1-2012, BSMI (Taiwan): CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital), C-Tick (Australia): AS / NZS CISPR22: 2009, GOST (Russia / CIS): GOST R 51317 Series, GOST 22505-97, EN55022: 2006 + A1: 2007, EN55024: 1998 + A1: 2001 + A2: 2003

• Environment

  ENERGY STAR 6.0 (USA)

• Safety

  CB (Europe): IEC60950-1 / EN60950-1, UL (USA): cUL60950-1, CCC (China): GB4943.1-2011, PSB (Singapore): PSB + IEC60950-1, NOM (Mexico): Tuner: NOM-001-SCFI-1993, Tunerless: NOM-019-SCFI-1998, KC (Korea): K 60950-1, IRAM (Argentina): IRAM + IEC60950-1, EAC (Russia): EAC + IEC60950-1, INMETRO (Brazil): INMETRO + IEC60950-1, SASO (Saudi Arabia): SASO + IEC60950-1, BSMI (Taiwan): BSMI + IEC60950-1, CSA (Canada): cUL, RCM (Australia): IEC60950-1 / AS / NZS 60950-1, BIS (India): IEC60950-1 / IS13252, TUV (Germany): CE, NEMKO (Norway): CE

Accessory

• Included

  Quick Setup Guide, Warranty Card, D-Sub cable, Power Cord, Remote Controller, Batteries, RS232C (IN) adapter, Cover-Jack, Screw (M3L8, 1 EA) (M4L8, 4 EA)
